The arm adopts cross-folding and staggered folding method, which minimizes the folded size and facilitates transfer and transportation
One body, strong and durable
The new E-series upgrade products adopt a new one-piece molding process to simplify the fuselage from dozens of original parts into a whole body. The body is made of high-strength, impact-resistant materials, which are strong and resistant fall
Fully waterproof body
The body adopts streamlined design, bright red coating, simple and beautiful appearance, and the surface is UV-treated, scratch-resistant, corrosion-resistant, overall dust-proof and waterproof, and can be washed directly with water
Integrated power supply wiring
Integrated power supply wiring, centralized power supply, separate signal and power supply, reduce interference
Enlarging the tank inlet
The tank filling mouth is enlarged as a whole to reduce the leakage of tank and make the tank process more smooth
Reinforced power plug
The main power cord is routed out from the side, and the battery interface is fixed on the side of the tripod, avoiding the obstruction of the plug when replacing the battery, and the plugging and unplugging connectors are safer and more stable (optional AS150/AS150U plugs)
Detachable camera mount
A detachable camera adapter is designed on the front of the frame, which can be installed or closed according to needs
Product parameters
E410P
Motor
X8
Propeller
30inch
ESC
80A FOC
Supply voltage
12S
Wheelbase
1416mm
Opening size
1801*1801*567mm
Folding size
701*701*567mm
Tank capacity
10L
Frame weight
5kg
E416P
Motor
X9
Propeller
34inch
ESC
80A FOC
Supply voltage
12S
Wheelbase
1362mm
Opening size
1848*1848*611mm
Folding size
680*680*611mm
Tank capacity
16L
Frame weight
5.07kg
E420P
Motor
X9PLUS
Propeller
36inch
ESC
80A FOC
Supply voltage
14S
Wheelbase
1462mm
Opening size
1954*1954*663mm
Folding size
713*713*663mm
Tank capacity
20L
Frame weight
5.14kg
Optional accessories
extended rod nozzles
brushless water pump
brushed water pump
RTK/antenna adapter
The assembled agricultural drone display
